Graphic Equalizer – 31 Band, Stereo

The Hybrid S-EQ231A is a stereo 31 band graphic equalizer that is suitable for frequency tuning to any sound system or band. It also doubles up as a basic active crossover with the inclusion of a separate Sub-output with a crossover frequency control, 30Hz-200Hz
The S-EQ231A features 20mm frequency bandwidth faders that are switchable between +/- 6 & 12dB, rotary level controls and a low-cut switch.

S-EQ231A
31 Band, Stereo Graphic Equalizer
Frequency Bands: 31, switchable between +/- 6dB & +/-12dB
Face Panel Controls: 20mm Frequency band faders, Low-cut switch, Bypass switch, Range switch
Face Panel Indicators: Range LEDS, Bypass LED & Low-cut LED
Inputs (CHA & CHB): Balanced XLR Female, Balanced 1/4″ Jack
Outputs (CHA & CHB): Balanced XLR Male, Balanced 1/4″ Jack
Output (Sub-Out): Balanced XLR Male with crossover frequency control, 30Hz-200Hz
Output Controls: Ground lift swich
PSU: Internal
Housing: Metal chassis, 19″ rack mount, 2U high
