The LCB244 is a LED bar with 4-in-1 RGBW LEDs. The unit is divided in 8 separately controllable sections. While using the fixture in stand-alone mode there are 54 pre-programmed shows that you can run automatically or sound activated, pick from the pre-set colour macros or create your own mixture of colours in RGBW mode. The extra P-Con output enables you to simply link the power of multiple units together into a single socket. Convection cooling for noiseless operation!
FEATURES:
- 24x 4W 4-in-1 LEDs
- RGBW Colour mixing
- Colour presets
- Pre programmed shows
- Electronic Dimming: 0 – 100%
- DMX and Stand-alone mode
- Master/slave function
- Sound activated with adjustable sensitivity
- Auto mode with adjustable speed
- DMX in/output via 3-pin XLR
- Control panel with LED display
- Aluminium housing
- Powerconnector input/output
- Incl. Quick Lock Brackets
SPECIFICATIONS:
- Product colour: Black
- Light source: 4-in-1 LED
- Colours: Red, Green, Blue, White
- LED power (single LED): 4W
- Quantity of LEDs: 24
- Beam angle: 11°
- Field angle: 24°
- Illuminance: 13.157 lx @ 1m
- Flash rate per second: 1 – 23Hz
- Modes: Automatic programs, DMX, Manual, Master/Slave
- Sound to light mode: Yes
- RDM: Yes
- DMX channels: 4, 6, 9, 32, 36
- DMX connection: 3-pin XLR
- Daisy chain: Yes (max. 6 bars)
- IP rating: IP20
- Cooling: Convection
- Display: LED
- Power plug: P-Con
- Power consumption: 1.983 – 0.912A
- Power supply: 100-240VAC 50/60Hz
- Dimensions (L x W x H): 1000 x 55 x 105mm
- Weight (kg): 2.4500
- Included accessories: Mounting bracket, Power cable
