I/O Box with 16 Remote-Controllable Midas Preamps, 8 Outputs and AES50 Networking featuring Klark Teknik SuperMAC Technology
FEATURES:
- 16 Midas-designed, fully programmable mic preamps for audiophile sound quality
- 8 analogue, servo-balanced XLR outputs
- AES50 network ports featuring Klark Teknik’s SuperMAC networking capability for ultra-low jitter and latency
- ULTRANET connectivity for Behringer’s P16 personal monitoring system
- Digital audio and control connectivity for Turbosound speaker systems with ULTRANET networking capability
- Dual AES50 ports for cascading additional S16, SD16 or SD8stageboxes—no merger or router required
- Precise LED metering plus 7-segment displays for signal control on stage
- Dual ADAT outputs providing 16-channel digital output on two optical TOSLINK connectors
- Phones output assignable to any of the inputs/outputs for on-stage monitoring
- MIDI In/Out for bi-directional communication between Behringer X32 Series console and on-stage MIDI devices
- Remote operation via shielded CAT5e cable up to 330 ft / 100 m length
- USB connector for system updates via PC
- “Planet Earth” switching power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
- “Built like a tank” yet compact, all-steel 2U rack-mount chassis
SPECIFICATIONS:
- Inputs: 16 MIDAS-designed remote-controllable preamps
- Outputs: 8 balanced XLR outputs
- Connectivity: Dual AES50 ports for digital audio networking
- Audio Quality: 24-bit signal transmission
- Monitoring: Per-channel signal and clip LEDs
- Integration: Compatible with X32, M32 and AES50 systems
- Expansion: Daisy-chain multiple S16 stage boxes
- Control: Remote preamp and phantom power control
- Mounting: 2U rackmount design
- ULTRANET: Integrated ULTRANET personal monitoring output
