QuickQ Rack is a small rack mountable version of the QuickQ console designed for installations. It features the same operating system as QuickQ series consoles, but is designed to operate as a remote system without physical user control.

Featuring 10 playback/execute buttons on the unit, the QuickQ Rack is ideally paired with 10Scene wall plates.

Supporting four universes QuickQ Rack is ideal for installations, control rooms and bars. The unit can be used as a desktop box or rack mounted with the supplied rack ears.

Key Features

Ideal for installations and architectural settings
Featuring four Universes of DMX output
Two RDM-enabled 5-pin DMX connectors
Built-in Wi-Fi for programming and remote control
Ten buttons for activation of Cues and Playbacks
Four 10Scene ports for connection of up to 40 10Scene wall plate
Features the same intuitive software as QuickQ Consoles
Simple Hot-Takeover mode allowing an external console to take control

General Specifications

Universes Supported: 4
Direct DMX Outputs 5-Pin XLR: 2
10Scene Buttons: 10
External Monitor: 1920 x 1080 HDMI
Built-in Wi-Fi: Yes
Network Port: 1
USB Ports: 2
Audio Input: 1
Audio Output: 1
MIDI Ports in/out: Yes
TrueCon Power Input: 90-250v AC
Max Number of DMX Channels: 2048
Max Number of Fixtures Supported: 2048
Max Number of Scenes: 10
Midi & Midi Timecode Supported: Yes
OSC Supported: Yes
Software
- RDM Autopatch for fast show patching
- Fixture library of over 30,000 fixture files
- Built-in FX generator
- Colour picker and Gel inbuilt Gel library
- Offline designer software available for Windows and Mac
Supported Fixtures: All – LEDs, Dimmers & Moving Lights
Dimensions (WxDxH): 403mm (without ears) x 195mm x 45mm / 15.8″ (without ears) x 7.7″ x 1.8″
Weight: 3.1kgs / 6.8lbs
Accessories Included: 1x Wi-Fi antenna, 2x rackmount ears, 4x 10Scene connectors, 1x Neutrik powerCON TRUE1 power cable

Price-Flex

Price Flex

Name: ChamSys QuickQ Rack
Brand: Chamsys
SKU: CHAM-QUICKQ RACK
Availability: InStock
