Compact and Precise

The LINEAR 9 118 Sub A is a true powerhouse. Its bass-reflex construction allows for compact dimensions, and weighing in at just 42 kilograms, it is extremely easy to transport. A powerful punch, precise playback and impressive low frequency performance make this active bass the ideal complement to the mid/high units. What’s more, it meets all the requirements for quickly and easily implementing effective cardioid setups, both mechanically and with the available filter sets. Thanks to its stereo preamplifier, it is also ideal for use in 2.1 systems.

General Specifications

Max. SPL @ 10% THD: 129 dB half space (42 Hz – 100 Hz averaged)
Max. SPL peak @ 10 % THD: 131 dB half space
Frequency response +/-3 dB: 42 Hz – X-over
Frequency Response -10 dB: 38 Hz – X-over
Power Amp Output (Peak Power): 1000 W
Amp Type: Class D
LF Driver: 1X 18″, 4″ voice coil
Maximum Input Level: +20 dBu
Analog Inputs: 2X XLR combo balanced
Analog Thru: 2X XLR balanced
DSP Out: 1X XLR balanced
Network Port: Ethercon RJ45, 1x In, 1x Thru
Filter Presets: Front, Cardioid 1:1, Cardioid 2:1, Remote
Remote Software: DSP CONTROL (Windows, macOS)
DSP Functions: Fully parametric 10-band EQ with variable filter characteristics, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
Sample Rate: 96 kHz
System Latency: Less than 2.6 ms
Mains Connector: 1x Powercon NAC3 In, 1x Powercon NAC3 Thru, 100–240 V
Power Consumption: 1.9 A / 100–240 V nominal according to EN 62368-1
Pole Mount: 1x M20
Carrying Handles: 2x MultiGrip
Housing: Birch multiplex
Finish: PU coating black
Front Grille: 2 mm metal grille backed with black acoustic foam
Dimensions (WxHxD): 55cm X 56cm X 69cm / 21-21/32″ X 22-3/64″ X 27-11/64″
Weight: 41.5 kg / 91.5lbs

Price-Flex

Price Flex

Name: HK Audio Linear 9 118 Sub A
Brand: HK Audio
SKU: LINEAR 9 118 SUBA
Availability: InStock
