Designed for professional wireless setups, the JTS UA-5800 UHF antenna distributor delivers stable RF distribution from two antennas to multiple receivers. With built-in RF amplification and integrated DC power, it ensures optimized signal performance and a tidy, dependable rack installation.

FEATURES:

For operating up to four UHF PLL receivers of the UF/US/IN series with one pair of antennas
With this device, it is not longer required to use the respective antennas and plug-in power supplies of the individual devices
Frequency range: 470-960 MHz
Power supply via four low-voltage outputs (4 x DC 12 V/1 A max.)
Each antenna to be connected via BNC jacks
Additional connection for cascading further antenna splitters
Supplied with suitable connection cables
Power supply for optional antenna booster UB-900I directly via UA-960 (can be deactivated internally)

SPECIFICATIONS:

Frequency Range: UHF 470~960MHz
Attenuation: -31dB ~ 0dB
Band Band Width: 60MHz / Step: 10MHz
Band Band Width: Lo Band : 470-710MHz ; Hi Band : 720-960MHz (Filter Option)
Cascade output level: 0dB ~ +2dB
Output Connection Isolation: ≧25 dB
Third Order Intercept Point: 24 dBm
Impedance: 50 Ohm
Power Consumption: 74W
Input AC Voltage: 100~240 VAC; 50/60 Hz: 2A
Output DC Voltage: +12V/0.5A x 8
Antenna Booster DC Voltage: 12V/400mA

Price-Flex

Price Flex

Name: JTS UA-5800 UHF ANTENNA DISTRIBUTOR
Brand: JTS
SKU: 171.911JTS
Availability: OutOfStock
