X Series

Multi-functional mixer with excellent sound performance and stability. Built-in USB playback, can also be connected to a variety of external devices. Super function, suitable for a variety of small and medium-sized activities, conferences, multi-function hall, small performance requirements.

Key Features

18 Inputs, 12 Mono microphones, and 3 Stereo Microphones
Channel 3 parametric equalizer, independent monitor output, earphone monitor output
COMP pressure limit, PAN sound and image positioning, mute switch, signal distortion monitoring light
Main channel L/R, SUB grouping, PFL solo bus signal distribution button
60mm high precision level attenuation fader
AUX auxiliary sending, effect FX sending function, REC recording output
2-way stereo auxiliary return input external electronic equipment, easy to use
Support 24-bit/192kHz HD recording PC USB 2.0 interface
Bluetooth, USB interface, play and save audio files
Built-in 99 kinds of 24BIT DSP preset effect types, color display
SUB1/2 group output, double 12-segment level monitoring, 48V phantom power supply
Built-in 100V/240V, 50-60Hz broadband power supply
12 MIC Input, 12 Mono + 3 Stereo
3 band EQ
PAN, MUTE, THD signal lamp
60mm logarithmic fader
Group output of SUB1/2
Double 12 level monitoring.
48V phantom power supply.
Independent monitoring + Headphones monitoring for output.
L/R on main channel, SUB group, SOLO and other bus signal distribution buttons.
2 stereo aux return input,PC USB-A 2.0 interface, can be used for USB playback and other electronic equipment.
Aux send + FX send ,REC input and recording output.
Built-in 99 kinds of 24BIT DSP +digital display.

General Specifications

Model	T1804BT-USB
Channel	4 Mono+3 Stereo
EQ	3 Band
AUX output	1
Return	1 Stereo
effectors	99 DSP
Main Output	1 Stereo
Phantom Power	48V DC

USB Player	√

			MIC	LINE	MIC	LINE
GAIN	GAIN		10～60	-10～40	一	-20～20
	AUX	0dB ( PRE )	一	一	一	一	一
		0dB ( POST )	10	-10	一	-22	一
		MAX( POST )	81	61	一	33	一
	MONITOR OUT	MAX ( ALL MAX )	78	64	一	43	40
	MONITOR OUT	0dB ( GAIN Control at MIN )	5	-16	一	9	15
	PHONES OUT	MAX ( ALL MAX )	84	61	一	50	40
	PHONES OUT	0dB ( GAIN Control at MIN )	10	0	一	15	15
	GROUP OUT	MAX ( ALL MAX )	86	67	一	46	一
	GROUP OUT	0dB (GAIN Control at MIN )	15	-5	一	17	一
	STEREO OUT	MAX ( ALL MAX )	86	67	一	46	19
	STEREO OUT	0dB (GAIN Control at MIN )	15	-5	一	17	0
	CH INSERT OUT	MAX(Control at Max)	60	44	一	一	一
	CH INSERT OUT	0dB (GAIN Control at MIN)	11	-13	一	一	一
	REC OUT	MAX	75	60	一	38	一
Signal to Noise Ratio		STEREO OUT	79	64	一	84
Signal to Noise Ratio		PHONES OUT	79	65	一	85
Noise (Control at MIN)		PHONES OUT (Fader at 0dB)	-90
		STEREO OUT (Fader at 0dB)	-73
		STEREO OUT (Fader at MIN)	-87
		CH INSERT OUT	-95
