The dual channel video switcher mixer for the streaming generation, mini-pro features four resolution independent inputs – up to full 4K60 to take advantage of native high-performance sources, whether cameras or laptops, without compromise. While presets for PIP and PBP are provided, mini-pro includes full pixel-to-pixel scaling capabilities for both the PIP and background video layers – truly unique in a streaming mixer of this size – features usually found only on larger professional video mixers.

Audio for output is selectable from embedded sources or an external source. Both Line and Mic level audio a supported on board with variable delay controls to bring audio into sync if needed.
In addition to HDMI and USB 3.0 streaming outputs, mini-pro includes a dedicated USB recording port. Simply connect a portable drive and record directly from mini-pro.

The exclusive integral display not only shows video preview, but is touch enabled for natural operation of features and settings. Remote control is available via free companion apps for laptops and mobile devices too.

mini-pro is packed with features including dynamic output control, preview multi-view, picture in picture, Chroma Key, video transitions, on board PTZ camera controls and more

Key Features

mini switcher convenient to carry
Joystick Camera Control
4K HDMI inputs
Support recording via USB 2.0
Mix audio from multiple inputs
Chroma Key
Support for third party apps including OBS Studio
Built-in LCD for video previews
T-Bar switch and 14 transition effects
Support live streaming via USB 3.0
Embedded & Insert Audio witch Sync
Configurable PIP video overlay
Control remotely from XPOSE mini software for computers, mobiles and tablets

General Specifications

Connctors
- Inputs: 4×HDMI-A
- Output
  - HDMI 2K: 1×HDMI-A
  - Streaming: 1×USB TypeA
  - Recording: 1×USB TypeA
Audio
- In: 2×3.5mm Stereo Jack
- Out: 1×3.5mm Stereo Jack
Communication
- LAN: 1xRJ45
Power: 1xUSB-C
Performance
- Supported Protocol: PTZ VISCA
- Video Formats: HDMI 2.0 | HDCP 2.2
- Streaming Formats: ITU-T H.265 | ISO/IEC 23008-2
- Disk Formats: FAT32(≤32 GB) | exFAT(64GB~2T)
- Recording Formats: MP4 | WAV
- Color Space: RGB
- Video Sampling: 4:4:4 YUV
- Latency: <4 frames
- Line In Delay: Up to 8 frames
Power
- Input Voltage: DC 12V/1.5A (via plug pack supplied)
- Max Power: 20W
- Compatibility: USB Power Delivery (PD) 3.0
- Supported Cables
  - Certified USB
  - PD Aware
Environment
- Temperature: 0℃~60℃
- Humidity: 10%~85%
Dimensions: 180mm X 118.3mm X 58.4mm
Weight: 0.42kg

Price-Flex

Price Flex

Name: RGBlink mini-pro Streaming Switcher
Brand: RGBlink
SKU: RGB2300003031
Availability: InStock
