REVEAL 802

The custom 8″ woofer and 1” tweeter tell you exactly what is going on in your mix through the finely tuned active crossover filter. Combine this with a new 100 watt bi-amp module and you get rock-solid bass at any volume.

Custom tweaked by TANNOY’s in-house speaker guru, Dr. Paul Mills, the active cross-over filters of REVEAL 802 have absolutely impeccable timing.

This produces the ultimate sweet spot so that you can move around in your workspace without losing the stereo imaging of your mix – as well as invite people to sit in with you during mixing sessions. If you’re anything like us, you’re not only working on mixes but also listening to your favorite music! REVEAL 802 gives you the ultimate pathway for both.

With the Aux Link, setting up has never been easier. Use the included mini jack cable to plug into your favorite music player and link your monitors for an instant stereo setup – no need for external interfaces.

General

Frequency Response	42 Hz – 43 kHz
Max SPL	114 dB

Membrane Sizes

LF/Mid Range	8″ (200 mm)
HF	1″ Soft Dome (25 mm)

Bi-amp Output Power, RMS

Power Output	100 Watts
LF/Mid Range	75 Watts
HF	25 Watts
THD	< 0.4 %

Input Types and Impedances

Balanced	XLR, 20 kOhm
Unbalanced	¼” Jack, 10 kOhm
AUX Link	Mini Jack, 10 kOhm
AUX Link Output	Mini Jack

EQ Options

HF EQ Settings	-1.5 dB HF Cut / Neutral / +1.5 dB HF Boost
Crossover Frequency	1.8 kHz
Low Frequency Alignment	Optimized Front Port

Cabinet Dimensions

HxWxD, inches	15.4 x 10.0 x 11.8
HxWxD, mm	390 x 254 x 300

Price-Flex

Price Flex

Name: Tannoy REVEAL 802 Studio Monitors
Brand: Tannoy
SKU: TANREVEAL802
Availability: OutOfStock
