The CPD series of power amplifiers has become a trusted tool for many gigging musicians, tours and installations since its introduction in 2014.

The top-of-the-range CPD4800 delivers breathtaking power. This 2U Class H amp delivers a competitor busting and earth shattering 4800watts when bridged into 4Ω. Weighing in at only 23.5kg the CPD4800 also has the best weight:power ratio in the CPD series.

Key Features

New – 4800watts when bridged into 4Ω
New – 2 * 5-way binding posts
Robust construction
Parallel, Stereo and Bridge modes

Limiter switch
Status and clip LEDs
Thermal protect, Over-current protect, Output DC protect, Output short protect, Power on/off muting

Technology

Working in stereo, parallel and bridged modes CPD4800 is built for a multitude of sound system formations. Brand new class H topology has resulted in a dynamic, high headroom amp made for propelling your loudspeakers through thick and thin with complete clarity.

Precision Control

Large rotary dials accurately adjust gain levels, and you will know when to do so from the clear and simple front panel. A 4 segment led formation displays shows vital power status, level, limit and protect information, keeping the sound engineer in the know.

Easy cleaning

Amplifiers often work in hot and dusty environments and, over time, the fans of an amplifier can easily suck this in. Dirty cooling fans reduce efficiency and can lead to overheating. It’s for this reason that we made the CPD series easy to clean. Simply unscrew the front grille, bush off the air filters, and put the grille back on. This easy maintenance means that a CPD amplifier can survive in the most hostile of working environments.

SPECIFICATIONS

Stereo Power Output : RMS
8Ω x 2	1000W
4Ω x 2	1500W
Bridged Mono Power Output : RMS
8Ω	3000W
4Ω	4800W
Frequency Response	20Hz – 30kHz
Topology	Class H
Inputs	2 x XLR
Outputs	2 x NL4 (speakON compatible),2 x binding posts, 2 x XLR
Input Sensitivity & impedance
Sensitivity	0dBu (0.775Vrms)
Balanced XLR input	20KΩ
Maximum Input Level	22dBu (9.7Vrms)
Voltage Gain	42dB
Slew Rate	>40V / us
Crosstalk	<-75dB
S/N	>100dB
Distortion (1W)	<0.02%
Damping Factor	>300
Controls
Front panel	AC Switch, CH 1 and CH 2 Gain Knobs
Rear panel	Parallel, Stereo & Bridge Mode Switch; Limiter Switch
Protections	Thermal protect, Over-current protect, Output DC protect, Output short protect, Power on/off mute
Indicators	Power, Protect, Signal, Peak
Cooling	Variable Speed Fan
Dimensions	88 x 483 x 450mm
Net Weight	23.5kg / 51.80lbs
Gross Weight	27kg / 59.52lbs
