Lets look inside

Titan loudspeakers pride themselves on custom Wharfedale Pro drivers. The IRIS-X HF compression driver used in Titan-AX12 and Titan-AX15 features a 1.75″ voice coil and is unique at this price point.

All Titan Active models are bi-amplified. The internal amplifiers have been tuned specifically for the HF and LF drivers that we have chosen. This makes for perfect power and frequency transfer, resulting in the sonic experience that you’d expect from a Wharfedale Pro active loudspeaker.

Titan-AX models with IRIS-X

The coil size and electrical sensitivity of a loudspeaker transducer is critical to its performance. Titan AX loudspeakers now include our proprietary IRIS X design which delivers Increased coil Radius and Increased electrical Sensitivity. The radius of the coil ensures smooth heat dissipation during prolonged high volume use, while the increased electrical sensitivity ensures that the transducer converts as much electrical power into sound output as the laws of physics allow.

A hot transducer wastes energy, risks damage and distorts. IRIS X reduces this through improved heat dissipation and improved efficiency.

In real-world terms, IRIS X transducers deliver higher SPL with less distortion. They lead the market with specifications and are designed and built entirely within Wharfedale Pro.

Increased Radius Increased Sensitivity

SPECIFICATIONS

Model Name	Titan 8A MKII	Titan-AX12	Titan-AX15
System Type	Active 8” 2-way Bi-Amplified	Active 12” 2-way Bi-Amplified	Active 15” 2-way Bi-Amplified
Frequency Response (+/-3 dB)	70 Hz-20 KHz	55 Hz-20 KHz	50 Hz-20 KHz
Frequency Range (-10 dB)	65 Hz-20 KHz	50 Hz-20 KHz	40 Hz-20 KHz
Calculated Maximum SPL @1 m	124 dB	128 dB	129 dB
LF Transducer Size (mm / inches)	205 mm / 8”	305 mm / 12”	381 mm / 15”
Coil Size (mm / inches)	38.86 mm / 1.53”	64.26 mm / 2.5″	75 mm / 3.0″
HF Transducer Type	Compression Driver	Compression Driver	Compression Driver
Coil Size (mm / inches)	25 mm / 1”	44 mm / 1.75″	44 mm / 1.75″
Exit Size (mm / inches)	30 mm / 1.2”	25 mm / 1”	25 mm / 1”
Diaphragm Material	Mylar	Titanium	Titanium
Nominal Coverage (H x V)	Elliptical waveguide 90° x 60°	Hybrid Symmetry Horn 100° x 80°	Hybrid Symmetry Horn 100° x 80°
Amplifiers
Low-Frequency Power Amplifier RMS/Peak Watts	150/300 W (Class D)	250/500 W (Class D)	350/700 W (Class D)
High-Frequency Power Amplifier RMS/Peak Watts	30/60 W (Class D)	50/100 W (Class D)	70/140 W (Class D)
Controls—EQ	High (±10 dB)10 KHz Shelving Low (±10 dB) 100 Hz Shelving	Note – EQ changed by DSP knob	Note – EQ changed by DSP knob
DSP	None	6 user presets	6 user presets
Hi Pass switch		90 Hz	90 Hz
Amplifier Protection / Thermal protection	Yes	Yes	Yes
Low Line Voltage Shut Down	60% Nominal line voltage	60% Nominal line voltage	60% Nominal line voltage
Driver Protection	Independent LF and HF limiters	Independent LF and HF limiters	Independent LF and HF limiters
DC Protection / Short Protection	Yes	Yes	Yes
Clip Limiter	Turns on ~150 W output	Turns on ~250 W output	Turns on ~350 W output
Limiter Indicator / Power Indicator	Red LED / Green LED	Red LED / Green LED	Red LED / Green LED
Connectors
Input – type	Switchable balanced mic/line level	Switchable balanced mic/line level (Chan 1)	Switchable balanced mic/line level (Chan 1)
Input Connector	XLR 1/4”Combo Jack	2 * XLR & 2 * 1/4″ jack (Chan 1 Line/MIC)	2 * XLR & 2 * 1/4″ jack (Chan 1 Line/MIC)
Line Output Connector	Switchable LOOP/MIX Balanced socket XLR	Switchable LOOP/MIX Balanced socket XLR	Switchable LOOP/MIX Balanced socket XLR
AC Power Supply	SMPS	SMPS	SMPS
AC Power Options	AC100-120 V~/220-240 V~,50/60 Hz	AC100-120 V/220-240 V~ 50/60 Hz	AC100-120 V/220-240 V~ 50/60 Hz
Hardware
Rigging / Bracket / Mounting Options	8 M6 threaded inserts inc 4 M6 threaded inserts on base in OmniMount 30.0-type footprint	10 M8 threaded inserts including 4 M8 threaded inserts on bottom in OmniMount 30.0-type footprint	10 M8 threaded inserts including 4 M8 threaded inserts on bottom in OmniMount 30.0-type footprint
	35 mm with lock screw	35 mm receptacle with lock screw	35 mm receptacle with lock screw
	1 carry handle on side	2 carry handles (one on each side)	2 carry handles (one on each side)
	Optional wall-mount bracket	Optional wall-mount bracket	Optional wall-mount bracket
LED Horn lighting (On/Off switch)	Yes	Yes	Yes
Enclosure Material and finish	Injection Moulded Polypropylene	Injection Moulded Polypropylene	Injection Moulded Polypropylene
Colour Options	Grey / White / Black	Black / White	Black / White
Grille Material & Finish	1.2 mm steel	1.2 mm steel	1.2 mm steel
Dimensions – Unpacked – Height	396 mm / 15.59”	582.7 mm / 22.9″	728.5 mm / 28.7″
Width Front	266 mm / 10.47”	384.6 mm / 15.1″	480.6 mm / 18.9″
Depth	221 mm / 8.7”	318.6 mm / 12.5″	395.6 mm / 15.6″
Dimensions – packed – Height	463 mm / 18.2”	663 mm / 26.1″	830 mm / 32.7″
Width Front	325 mm / 12.8”	435 mm / 17.1″	514 mm / 20.2″
Depth	282 mm / 11.1”	408 mm / 16.1″	489 mm / 19.3″
Net Weight (kg / lbs)	6.25 kg / 13.75 lbs	12.4 kg / 27.28 lbs	22.94 kg / 50.3 lbs
Gross Weight (kg / lbs)	8.75 kg / 17.94 lbs	15.5 kg / 34.1 lbs	27.7 kg / 60.9 lbs

Price-Flex

Price Flex

Name: Wharfedale Pro TITAN AX15B
Brand: Wharfedale Pro
SKU: WHAR-TITAN AX15 B
Availability: InStock
