The WLA-312X separates low, mid and high frequencies across dedicated drivers for professional array applications. Its birch enclosure and integral rigging hardware suit engineered touring and fixed sound systems.
Key features
- Two 12-inch LF drivers, one 10-inch neodymium MF driver and two 2.55-inch voice-coil HF drivers
- 1410 W total AES power handling across LF, MF and HF bands
- 2820 W programme / 5640 W peak total power handling
- 90-degree horizontal coverage
- Birch plywood enclosure with rigging hardware
Technical details
- Frequency response: 50 Hz-18 kHz (+/-3 dB)
- Maximum SPL: 142 dB at 1 m
- Net weight: 58 kg
Sold as one passive array element. External multi-channel amplification, crossover/DSP and appropriate rigging accessories are required; these are not included.
