5-channel 19″ rack-mountable mixer-amplifier, designed for commercial sound installations to power 100V line speakers or standard low impedance speakers. Input options include XLR (with switchable phantom power), mic/line jack, and RCA line. A switchable ‘voiceover’ feature automatically lowers the background music volume when a signal is detected via mic input 1, and rear panel 24V contacts can mute all except mic input 1 when triggered. A built-in audio player section can play mp3 files from a USB or stream audio wirelessly from Bluetooth®. A main feature of the RM-WIFI models is the ability to connect to a wired or wireless network for streaming audio from internet radio, playback services or even from a local NAS drive. Setup and control for this function is entirely via the WiiM Home smart phone app with a choice of streaming services embedded. Outputs on screw terminal are via 4 switchable zones with a separate “always on” output for priority alert speakers.

FEATURES:

Internet radio or audio streaming from WiFi or LAN connection
Free WiiM Home Player app for Android or iOS
USB player and Bluetooth receiver
4 switchable 100V outputs and 1 unswitched output
Optional 4-16 Ohm output
XLR input with switchable +20V phantom power
2 x mic/line inputs, 2 x RCA line inputs, 1 x RCA line output

SPECIFICATIONS:

Weight7.37kg
FuseT3.15A
Output power : rms240W
Power supply170-264Vac, 50Hz (IEC)
DC power24Vdc (screw terminals)
InputsMic XLR, 2 x mic/line jack, 2 x RCA line
Input sensitivity : mic 1 (balanced)-53dBV
Input impedance : mic 15k Ohms
Input sensitivity : line (unbalanced)-15dBV (-18.5dBV line 5)
Input impedance : inputs 2-51k Ohms
Line outputRCA
Speaker outputs4 switched + 1 non-switched 100V / 4-16 Ohms / COM
Bluetooth version5.0
Network connectionRJ45 (LAN) or 2.4GHz WiFi (802.11 b/g/n)
Remote controlvia WiiM Home app for iOS or Android
ControlsMic1, mic/line2+3, line4+5, bass, treble, master volume
Equaliser : bass100Hz ±10dB
Equaliser : treble10kHz ±10dB
Rear panel switchesPhantom, Vox, Mic/Line (2 + 3)
Phantom power+20V (mic 1 XLR, switchable)
Audio sourceNetwork audio, USB player, Bluetooth receiver
Emergency control24V contacts – mute all except Mic.1 when triggered
THD<1.0%
Dimensions433 x 320 x 88mm

Price-Flex

Price Flex

Name: ADASTRA RM240D-WIFI 100V MIXER AMPLIFIER 240W USB/BT/FM/DAB+/WIFI
Brand: Adastra
SKU: 953.235AD
Availability: InStock
