12-Channel Powered Band Mixer
The CX12-800 is a compact designed 12-channel, 800W powered band mixer. Each input channel has a 2-band EQ and FX control, offering a low cost alternative with maximum output. The master control section features a 7-band equalizer, built-in MP3 player and stereo record out.
Technical Specifications
Mono Channels: 10 balanced XLR / 8 TRS
Stereo Channels: 2 balanced TRS
Channel EQ: 2-band low and high
Mono Channel Control: EQ, FX, gain and level
FX Control: Echo and delay
MP3 Player: USB or Bluetooth
Master Channel Control: +48V phantom power, headphone, 2-track / MP3 media, main, FX and level meter
Main Outputs: 2 balanced XLR
Power Outputs: 2 Speakon, 2x 400W RMS/4ohm
AC Mains Power Supply: IEC
Dimensions (W x D x H): 485 x 335 x 120mm
